Ubiquiti U7 Pro Max WiFi 7 Ceiling Access Point | 8-Stream, 6 GHz, 2.5 GbE

Built for spaces where hundreds of devices need to stay connected at once, the U7 Pro Max runs on tri radio architecture across 2.4, 5, and 6 GHz bands, supporting up to 500 or more concurrent clients without a drop in performance. Its 8 stream design pushes throughput up to 8648 Mbps on the 5 GHz band alone, while a 2.5 GbE PoE+ uplink keeps the connection to the wired network from becoming a bottleneck. The access point also includes real time spectral analysis for smarter channel selection, helping it adapt automatically in environments with heavy wireless interference.

Physically, the unit is designed to blend into ceiling or wall installations, with a compact 206mm housing and support for both mounting orientations out of the box. It runs WPA3 and WPA2 Enterprise security, supports 802.1Q VLAN tagging, and includes guest traffic isolation and per user rate limiting for environments where network segmentation matters.

Core Features:

• 8 stream WiFi 7 access point with tri radio 2.4, 5, and 6 GHz support
• Supports 500+ concurrent connected devices
• 2.5 GbE PoE+ uplink via RJ45
• Throughput up to 8648 Mbps (5 GHz) and 5765 Mbps (6 GHz)
• Real time spectral analysis for automatic channel optimization
• WPA3 and WPA2 Enterprise wireless security, 8 BSSID per radio
• 802.1Q VLAN support with guest traffic isolation
• Coverage of up to 1,750 sq ft per unit
• Wall and ceiling mountable, included hardware
• Rated for -30 to 60°C operating temperature
