Yealink MVC S40-C5U-000, Microsoft Teams Rooms system for small to medium rooms
The Yealink MVC S40‑C5U‑000 is an integrated Microsoft Teams Rooms system tailored for small to medium meeting rooms. It includes the SmartVision 40 AIO (audio/video device), the MCore 4 (Gen‑4 Mini‑PC with Intel Core U/NPU), an 11.6″ MTouch Plus panel, and a RoomSensor. It ships with Windows 11 IoT Enterprise and Teams Rooms pre‑installed, and supports AI-rich conferencing features with intuitive meeting control and easy deployment
Description:
- SmartVision 40 All‑in‑One A/V Device – Integrates dual 48 MP cameras, microphones, speakers, and AI features in one unit
- Dual‑lens 48 MP Video – Uses fixed‑focus stitching to produce ultra‑HD clarity with a 120° diagonal field of view
- AI Conferencing Functions – Supports IntelliFocus, IntelliFrame (multi‑stream), and Video Fence to track speakers, frame participants, and block distractions
- Built‑in Audio Array – Eight MEMS microphones providing ~6 m (19 ft) voice pickup with full‑duplex and AI noise cancellation
- Stereo Speaker Output – Integrated stereo speakers delivering clear meeting room audio
- Expandable Mic Support – Can connect two optional expansion microphones for larger setups
- RoomSensor for Automation – Detects room occupancy, wakes system automatically, and displays temperature/humidity on the touch
- MTouch Plus Touch Panel – 11.6″ narrow‑bezel 1080p touchscreen for Teams control, one‑touch join, call and content management
- MCore 4 Mini‑PC (Gen‑4) – Powered by Intel Ultra5 125H (11th Gen i5) CPU with integrated NPU for AI processing
- 16 GB DDR5 RAM and 256 GB SSD – High‑speed memory and storage preloaded with Windows 11 IoT and Teams Rooms app
- Multiple Outputs & Ports – 3× HDMI outputs (CEC supported), USB‑A, USB‑C, Ethernet (Gigabit), TPM 2.0, EDID, Kernel DMA protection
- Wired & Wireless Content Sharing – Supports HDMI/USB‑C in + WPP30 wireless up to 1080p @30 fps, plus Miracast support
- One‑Cable Connectivity – Single CAT5e cable links MCore 4 and MTouch Plus for power, data and control
- Native Microsoft Teams Interface – Familiar Teams UI, one-touch meeting control, integrated camera & content control via MTouch panel
- Remote Device Management – Integrated with Yealink Device Management Cloud platform for remote monitoring, configuration, and firmware updates
- Sustainable Design – ISO 14064‑3:2019 verified Product Carbon Footprint, emphasizing low‑carbon manufacturing and lifecycle transparency
- 2‑Year Hardware Warranty – Included for the packaged equipment (SmartVision 40, MCore 4, MTouch Plus, VCM mics)
New
Data sheet
| Camera | 2x 48 MP Camera |
|---|---|
| Display | 11.6-inch narrow bezel IPS display |
| Memory | 6GB(2*8GB) DDR5 |
| Operating humidity | 10-95% |
| Operating temperature | 0-40℃ |
| Resolution | 1920 x 1080 video resolution |
| Storage size | 256GB SSD |
| Built-In Speaker | 2 x 10W Stereo speakers |
| BIOS feature | 3x HDMI video output -CEC -EDID , TPM2.0 , Kernel DMA |
| Package Content | MCore 4 , MTouch Plus , RoomSensor , SmartVision 40, All-in-One Audio and Video integration machine |
| Preload | Windows 11 IoT Enterprise X64 , Windows 11 IoT Enterprise License , Microsoft Teams Rooms App , Yealink RoomConnect |
| Detection Angle | 120° |
| Adjustable Detection Angle | ±20° |
